MYZG CPCY80 8T Off-Road Forklift: The Heavy-Lift Titan for the Toughest Terrains
When the workload reaches a massive 8000kg, and the terrain is anything but paved, you need the MYZG CPCY80 8T Off-Road Forklift. Engineered by Shandong Mingyu Heavy Industry (SDZG), this heavy-duty machine is built to dominate construction sites, mining operations, and industrial yards where standard forklifts simply cannot survive.
Combining a high-torque QUANCHAI 81kW diesel engine with a specialized rear-steering system, the CPCY80 offers the perfect balance of extreme lifting power and precision maneuverability.
Unrivaled Power and Drivetrain Performance
RATED LOAD LIFTING CAPACITY
8000KG
LOAD CENTRE DISTANCE
500mm
TOTAL WEIGHT
8260KG
FORK LENGTH
1200MM
ENGINE MODEL
QUANCHAI 4C9-105M22
RATED POWER
81KW
RATED SPEED
2400R/MIN
DIMENSION
5670*2120*2750MM
STANDARD LIFTING HEIGHT
3000MM
TRANSMISSION
280
TYRE TYPE
16/70-20
MIN.TURNING RADIUS
3505MM
maximum driving speed
28km/h
Wheel Track
1710mm
Wheel base
2730mm
Rear steering
Unrivaled Power and Drivetrain Performance
The CPCY80 is designed to handle the most demanding heavy-lift cycles under extreme thermal and physical stress.
High-Output Diesel Engine: Powered by the QUANCHAI 4C9-105M22, delivering a robust 81kW of output at 2400R/min. This ensures that even with an 8-ton load, you have the necessary torque to climb inclines and navigate deep mud or gravel.
Heavy-Duty Transmission: Utilizing the Model 280 transmission, specifically tuned for the high-torque demands of off-road material handling.
Industrial-Grade Tires: Equipped with massive 16/70-20 off-road tires, providing superior ground clearance and the "flotation" needed to prevent sinking in soft or unstable soil.
Precision Engineering: Rear-Steering Advantage
Managing 8 tons of material requires more than just power—it requires control. The Rear Steering configuration of the CPCY80 allows for an incredibly tight minimum turning radius of 3505mm. This enables the operator to pivot heavy loads with surgical precision in cramped industrial zones or narrow timber yards.
1. Superior Stability & Counterweight
With a total overall weight of 8260kg and a wide 1710mm wheel track, the CPCY80 acts as its own rock-solid anchor. The 2730mm wheelbase ensures that the center of gravity remains low and balanced, even when the mast is fully extended on uneven ground.
2. High-Visibility Panoramic Cabin
The reinforced cabin features expansive glass surfaces, giving the operator an unobstructed 360-degree view of the job site. This visibility is critical for safety when transporting massive loads near ground personnel and other heavy machinery.
3. All-Weather Reliability
From the high-strength hydraulic hoses to the heavy-duty manganese steel mast, the CPCY80 is built to withstand extreme temperatures and corrosive environments common in mining and coastal harbor operations.
Low Maintenance, High Durability
Mining & Quarries: Moving heavy ore blocks and equipment across unpaved roads.
Large-Scale Construction: Transporting pre-cast concrete and structural steel on site prep areas.
Lumber & Forestry: Handling massive logs and timber stacks in muddy sorting yards.
Harbor & Logistics: Rapidly moving containers and heavy industrial crates over rough port surfaces.
Oil & Gas Infrastructure: Reliable material handling in remote, off-road pipe yards.
DIFFERENTIATED PRODUCTS
According to different applications, various attachments are for option
Global Industry Applications
The MYZG Off-Road Forklift is the preferred choice for:
Construction & Infrastructure: Handling pallets of bricks, steel, and cement on unpaved ground.
Lumber & Forestry: Moving heavy timber through muddy yards.
Agriculture: Transporting bulk feed, equipment, and produce across natural terrain.
Mining & Quarries: Reliable material transport in high-dust, high-vibration environments.
Why Choose MYZG?
As a leader in heavy machinery, MYZG ensures that every CPCY80 is built to international standards. We provide factory-direct support, ensuring your heavy-duty off-road forklift remains a productive asset for years to come.
