WZ25E electric backhoe loader
MYZG WZ25E Compact Electric Lithium Backhoe Loader (154V / 31kWh)
Zero Emissions, Ultra-Quiet Electric Power: 4200kg Operating Weight, 1000kg Rated Load, 18kN Breakout Force, and Advanced 31kWh High-Voltage Battery Architecture.
Executive Overview: Clean, Eco-Friendly 2-in-1 Excavation & Loading Innovation
The MYZG WZ25E Lithium Electric Backhoe Loader represents the next generation of eco-friendly, zero-emission earthmoving machinery designed by MYZG Machinery. Engineered to meet strict international environmental standards, carbon-neutral jobsite demands, and urban noise restrictions, the WZ25E seamlessly combines the utility of a front loader and a rear excavator onto a pure electric 4x4 platform.
Powered by a high-capacity 154V / 206Ah (31kWh) lithium battery system, the WZ25E delivers instant hydraulic response and massive motor torque with zero tailpipe emissions and low operational noise. Boasting an operating weight of 4200 kg, a front rated loading capacity of 1000 kg (2000 kg tipping load), 18 kN breakout force, and 28 kN maximum traction force, this compact electric backhoe loader is ideal for indoor construction, agricultural greenhouses, residential trenching, and night-time urban utility projects.
MYZG WZ25E Factory Technical Specifications
Examine the comprehensive technical parameters and performance data for the MYZG WZ25E Electric Lithium Backhoe Loader:
| Specification Parameter | Factory Data Detail |
|---|---|
| Model Identification | WZ25E (Electric Series) |
| Overall Operating Weight | 4200 kg |
| Power System (Battery Voltage & Capacity) | 154V / 206Ah |
| Power System (Total Battery Energy) | 31 kWh |
| Rated Loader Lifting Load | 1000 kg |
| Loader Tipping Load | 2000 kg |
| Max. Breakout Force | 18 kN |
| Max. Traction Force | 28 kN |
| Rated Loader Bucket Capacity | 0.45 m³ – 0.6 m³ |
| Excavator Bucket Capacity | 0.04 m³ |
| Max. Dumping Height | 3300 mm |
| Corresponding Dumping Distance | 440 mm |
| Max. Excavation Height | 3665 mm |
| Max. Excavation Depth | 2360 mm |
| Overall Dimensions (L × W × H) | 5600 × 1950 × 2750 mm |
| Wheelbase | 1220 mm |
| Track Width | 2300 mm |
| Minimum Turning Radius | 2850 mm |
| Tyre Size Specification | 10.5/45-16 |
Engineering Breakdown & Key Product Advantages
1. 154V/206Ah (31kWh) Lithium Power System & Lower Operating Costs
The WZ25E is powered by an advanced 154V / 206Ah high-voltage lithium battery pack providing 31 kWh total energy. Electric drive eliminates diesel fuel costs, engine oil changes, air filter replacements, and exhaust maintenance—slashing daily operating expenses by up to 70%. Fast-charging technology allows quick battery top-ups during operator rest periods, ensuring continuous productivity throughout the shift.
2. 18kN Breakout Force, 1000kg Rated Load & Instant Hydraulic Torque
Electric motors deliver peak torque instantly upon acceleration. The WZ25E delivers a strong 18 kN breakout force and 28 kN traction force, allowing the 0.45m³ - 0.6m³ front bucket to easily scoop packed dirt and aggregates. With a rated load of 1000 kg and a safety tipping load of 2000 kg, it reaches a maximum dumping height of 3300 mm (440 mm dumping distance), ideal for loading medium trucks and hoppers.
3. 2360mm Excavation Depth & Ultra-Compact 2850mm Turning Radius
The rear excavator arm features a 0.04m³ digging bucket, offering a maximum excavation depth of 2360 mm and a maximum digging height of 3665 mm. Designed for tight spaces, the machine has overall dimensions of 5600 × 1950 × 2750 mm, a 1220 mm wheelbase, and an ultra-tight 2850 mm minimum turning radius—allowing easy maneuvering inside building structures, narrow urban alleys, and indoor farm sheds.
Target Application Environments
The zero-emission, low-noise profile of the MYZG WZ25E opens up new operational opportunities where diesel machinery is restricted:
Indoor Construction & Tunnels
Digging inside closed buildings, underground basements, and tunnels without ventilation hazards.
Urban Utility & Night Work
Excavating cable trenches and water pipes in residential zones during quiet night hours without noise complaints.
Agricultural Greenhouses & Livestock
Handling fertilizer, feed, and earthwork inside livestock barns and enclosed agricultural greenhouses clean and exhaust-free.
Frequently Asked Questions (FAQ)
Q: What is the battery capacity and voltage of the WZ25E electric backhoe loader?
A: The WZ25E is equipped with a 154V / 206Ah lithium battery pack supplying 31 kWh total energy storage for high torque and long operational endurance.
Q: What is the rated loading capacity and maximum digging depth of the WZ25E?
A: The front loader has a rated load capacity of 1000 kg (0.45-0.6m³ bucket), while the rear backhoe arm offers a maximum excavation depth of 2360 mm.
Q: What are the main benefits of choosing an electric backhoe loader over a diesel model?
A: Key benefits include zero exhaust emissions, ultra-quiet operation, up to 70% savings on fuel and maintenance, instant hydraulic torque, and access to indoor and noise-sensitive jobsites.
Switch to Zero-Emission Power with the MYZG WZ25E Electric Backhoe Loader!
Contact MYZG Machinery export specialists today for direct factory quotes, custom battery charger configurations, hydraulic attachment options, and international shipping rates!
