E25 Electric Wheel Loader
Product Feature
The E25 is the first exclusively electric-powered wheel loader by MINGYU. Its performance characteristics correspond to those of a conventional diesel-powered machine. The installed 154-volt lithium-ion battery is optionally available in three power levels, so that running and charging times can be optimally matched to the work requirements.
The E25 works fully emissions-free on site and with significantly lower noise pollution. For the end user, this means greater flexibility in application, environmental protection and significant savings on operating costs.
Powerful lithium-ion battery
Depending on the application and purpose, the appropriate battery size can be selected. A total of three maintenance-free lithium-ion batteries are available
Easy charging options
The charging cover can be accessed easily from the outside on the machine. Behind it you will find the socket, the activation switch, and the charge display.
The charging cable (Type 2 plug on the machine, familiar from the automotive industry), including the control box, is available with a number of different plugs: 230 V / 10 A Schuko, 230 V / 16 A CEE (blue, 3-pole), 400 V / 16 A CEE (red, three-phase AC current, 5-pole), 400 V / 16 A (Type 2 plug wall box, IEC 62196), and other adapter plugs.
The flexible, selectable charging plugs enable fast and coordinated charging of the selected battery size. In combination with the installed on-board charger, both efficient and safe charging processes are guaranteed.
Parameter
voltage
154v
capacity
206ah
quantity of electricity
32kwh
rated load capacity
1200kg
rated bucket capacity
0.4m³
width of bucket
1.55m
wheel base
2200mm
wheel track
1135mm
dumping height
3300mm
tyre model
10.5/46-16
weight unladen
3400kg
size
4780*1550*2160mm
1. Passed CE quality certification.
2. Standard configuration with Quick Hitch and Electric Joystick, easier to operate.
3. Optional DC battery system and AC battery system, with zero-pollution.
4. Maintenance-Free Batteries makes later use more convenient and more secure.
5. The small size can work in a small limited space, and is flexible in operation.
6. Multi-options for attachments.
DIFFERENTIATED PRODUCTS
According to different applications, various attachments are for option, such as extra-large coal bucket, log fork, grain bucket and grass fork etc.
